| Actuator Type |
Heavy-Duty Electric Linear Actuator |
| Rated Load |
3,200 N – 12,000 N |
| No-Load Speed |
6 – 37 mm/s |
| Stroke Length |
50 – 1,000 mm (Customizable) |
| Input Voltage |
12V, 24V, 36V, 48V DC (Brushed Motor) |
| Operating Temperature |
-10°C to +65°C (Optional: -40°C to +65°C) |
| Position Feedback Options |
Potentiometer, Hall Sensor, Limit Switch Signal |
| Operation Mode |
Electric Operation with Manual Override |
| Installation |
Clevis Mounting |
| Customization |
Stroke length, voltage, feedback, mounting options available |
Suitable Parking Application:Boom barriers, parking gates, automated parking systems
