YS-DJ878
YS-DJ878 (Pen-Type Electric Linear Actuator)
YS-DJ878 (Pen-Type Electric Linear Actuator)
Technical Specifications
| Parameter | Specification |
|---|---|
| Rated Load | Up to 2,000 N |
| No-Load Speed | 3.4–30 mm/s |
| Input Voltage | 12 V DC / 24 V DC |
| Stroke Length | Customizable, up to 1,000 mm (recommended) |
| Duty Cycle | 15% (Continuous operation under full load should not exceed 2 minutes) |
| Lead Screw Type | Trapezoidal Lead Screw |
| Motor Type | DC Brushed Motor (Standard); Brushless DC Motor (Optional) |
| Position Feedback | Hall Sensor |
| Limit Protection | Built-in bidirectional limit switches with automatic power cut-off at full extension and retraction |
| Protection Rating | IP65 (Dust and Water Resistant) |
| Housing Material | Corrosion-resistant Aluminum Alloy |
| Corrosion Resistance | NSS 480 Hours |
| Operating Temperature | -10°C to +55°C |
Key Features
- Compact pen-type design
- High-precision linear motion
- Long stroke up to 1,000 mm
- Optional brushless motor for extended service life
- Hall sensor feedback for accurate positioning
- Integrated bidirectional limit switches
- IP65-rated dust and water protection
- Corrosion-resistant aluminum housing (NSS 480h)
- Smooth, reliable, and low-maintenance operation
Typical Applications
- Dental Chairs
- Examination Tables
- C-Arm Systems
- MRI Equipment (Positioning Mechanisms)
